421 SN

Name: 421 SN
Brand: Palak Hydraulic
Price: 500.0 INR
Availability: InStock

Price 500.0 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

421 SN Specification

Application
Hydraulic systems for conveying petroleum-based hydraulic fluids

Use
Industrial, Construction, Earth Moving Equipment

Working Presssure
15.0 MPa (150 bar)

Hardness
Shore A 80 5

Product Type
Hydraulic Hose Pipe

Material
Synthetic Rubber, MS Wire

Finish
Smooth / Wrapped

Length
1-100 mtrs

Tube
Black, oil resistant synthetic rubber

Cover
Black, abrasion, weather and ozone resistant synthetic rubber, MS wire braided

Connection
MS wire braided

Temperature
-40C to +120C

Inner Diameter Range
8 mm to 50 mm

Outer Diameter Range
15 mm to 64 mm

Conforming Standards
IS: 226, SAE 100 R1AT, DIN-EN 853 1SN

Reinforcement
Single High Tensile Steel Wire Braid

Safety Factor
4:1

Minimum Bend Radius
From 100 mm (varies with size)

Operating Fluid
Petroleum/Oil based fluids

Burst Pressure
60.0 MPa (600 bar)

421 SN Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About 421 SN

Experience a fresh Promotion featuring our top-notch 421 SN Hydraulic Hose, engineered for superior performance where only majestic quality will do. Designed with a single high tensile steel wire braid, this hose offers a scarce blend of strength and durability, catering to safety with a 4:1 factor and a top-tier burst pressure of 60 MPa (600 bar). Perfect for conveying petroleum-based fluids, it fits an inner diameter range from 8 mm to 50 mm, and withstands temperatures from -40C to +120C. This abrasion, weather, and ozone-resistant hose conforms to IS:226, SAE 100 R1AT, and DIN-EN 853 1SN standards, ensuring reliability in the most demanding industrial and construction environments. Exported worldwide from India.

Features & Applications of 421 SN Hydraulic Hose

The 421 SN Hydraulic Hose is equipped with a single high tensile MS wire braid, ensuring robustness and top-tier reliability. Its black synthetic rubber cover is both abrasion and ozone resistant, with Shore A 80 5 hardness. Suitable for industrial, construction, and earth-moving applications, it can efficiently convey petroleum-based hydraulic fluids. The hose is ideal for rigorous usage types in hydraulic systems needing a minimum bend radius from 100 mm, tailored to heavy-duty performance and safety.

Export Markets, Packaging, and Certifications

421 SN hoses are offered to prestigious export markets across Asia, Africa, the Middle East, and Europe. Each order undergoes careful completion, with hoses packaged in rolls from 1 to 100 meters, using robust materials for protection during transit. Certified to IS:226, SAE 100 R1AT, and DIN-EN 853 1SN standards, these hoses guarantee top-notch quality and reliability, optimizing your expenditure for high-value hydraulic solutions on a global scale.

FAQ's of 421 SN:

Q: How does the 421 SN Hydraulic Hose ensure safety during usage?

A: The hose is constructed with a single high tensile steel wire braid and maintains a safety factor of 4:1, ensuring reliable and safe performance in demanding applications.

Q: What types of fluids can be conveyed using the 421 SN hose?

A: The 421 SN is designed specifically for petroleum and oil-based hydraulic fluids, making it compatible with a range of industrial and construction machinery.

Q: Where can the 421 SN Hydraulic Hose be applied?

A: It is ideal for use in hydraulic systems within the industrial, construction, and earth-moving sectors, handling high-pressure requirements with ease.

Q: When should I consider replacing the 421 SN hose in my system?

A: Replace the hose if you notice visible wear, cracking on the cover, or reduced performance, especially after long-term usage at high pressures or temperatures.

Q: What is the process for ordering and receiving the 421 SN hose internationally?

A: You can place orders directly through our export channels; each order is securely packaged and shipped globally, with completion times depending on order volume and destination.

Q: What are the key benefits of choosing the 421 SN hose for my operations?

A: Top-tier durability, compliance with international standards, flexibility in temperature and bending, and reliable performance make it a valuable choice for critical hydraulic applications.
